Bronze Fusible Plug

Name: Bronze Fusible Plug
Brand: Rushas Engineering Co. Pvt. Ltd.
Price: 1200 INR
Availability: InStock

Price 1200 INR/ Unit

Get a Price/Quote

MOQ : 1 Unit

Bronze Fusible Plug Specification

Condition
New

Pressure
Low Pressure

Usage
Use of the fusible plug is as a safety precaution against low water levels in steam boilers, when Temperature/Pressure Exeeds Specific limit.

Material
Bronze (As per IBR REG 282(a)GR. B)

Size
1/2

Product Type
Fusible Plug

Bronze Fusible Plug Trade Information

Minimum Order Quantity
1 Unit

Payment Terms
Cash in Advance (CID), Cheque, Cash Advance (CA)

Supply Ability
100 Units Per Day

Delivery Time
1-2 Week

Packaging Details
Corrugated Box Packing

Main Domestic Market
All India

Certifications
IBR Certificate

About Bronze Fusible Plug

Technical details

SPECIFICATIONS
MATERIAL	BRONZE (AS PER IBR REG 282 (a) Gr. B)
END CONNECTIONS	SCREWED BSPT 11TPI/14TPI
MANUFACTURING STANDARD	AS PER IBR 1950 cl 331-334
TESTING STANDARD	AS PER IBR 1950 cl 290 a
CERTIFICATION	IBR approved
SIZES	inch -1 inch

ONE PIECE - WATERSIDE / WET

Types
Size (inches)	Pressure (Kg/Cm 2)	Melting Temperature
1	17.5	265 Degree C
1	10.5	240 Degree C
3/4	17.5	265 Degree C
3/4	10.5	240 Degree C
1/2	10.5	269 Degree C
1/2	17.5	292 Degree C

TWO PIECE WATERSIDE / WET

Types
Size (inches)	Pressure (Kg/Cm 2)	Melting temperature
1	17.5	265 Degree C
1	10.5	240 Degree C
3/4	17.5	265 Degree C
3/4	10.5	240 Degree C

ONE PIECE FIRESIDE / DRY

Types
Size (inches)	Pressure (Kg/Cm 2)	Melting temperature
1	17.5	265 Degree C
1	10.5	240 Degree C
3/4	17.5	265 Degree C
3/4	10.5	240 Degree C
1/2	10.5	269 Degree C
1/2	17.5	292 Degree C

Reliable Boiler Safety with Bronze Fusible Plug

Crafted specifically for low-pressure steam boilers, the Bronze Fusible Plug offers peace of mind by automatically responding to critical temperature rises. Its bronze composition ensures longevity and compliance with leading industry standards, making it a trusted choice for safe boiler operation.

How the Fusible Plug Works

This fusible plug is designed to melt at a designated temperature, caused by a dangerous drop in boiler water levels. Once the fusing core liquefies, it vents steam to signal the boiler operator, preventing catastrophic damage and promoting operational safety.

Advantages of Using Our Fusible Plugs

Our Bronze Fusible Plugs offer dependable performance, high resistance to corrosion, and meet Indian Boiler Regulation standards. Selecting these plugs for your boiler systems brings enhanced reliability and adherence to statutory safety requirements.

FAQ's of Bronze Fusible Plug:

Q: How does the bronze fusible plug function in steam boilers?

A: The bronze fusible plug serves as a safety precaution by melting when the boiler's water level drops and the temperature rises excessively. This melting releases steam, warning operators and preventing potential boiler explosions.

Q: What are the advantages of using a bronze fusible plug over other materials?

A: Bronze offers superior corrosion resistance and durability under pressure and temperature fluctuations, ensuring a longer service life and compliance with IBR standards, especially important for boiler safety devices.

Q: When should fusible plugs be replaced in steam boilers?

A: Fusible plugs should be inspected regularly and replaced immediately if there is any sign of damage or after the plug has melted due to activation. Routine checks ensure continuous boiler safety and reliability.

Q: Where are bronze fusible plugs typically installed?

A: Bronze fusible plugs are typically fitted into the crown plate or top section of steam boilers, where the risk of low water exposure is highest. This positioning maximizes their effectiveness as a safety device.

Q: What is the process for installing a 1/2 inch bronze fusible plug?

A: Installation involves carefully threading the plug into a pre-designated opening in the boiler's structure, ensuring a secure, leak-free fit. It is essential to follow manufacturer and IBR guidelines for proper installation.

Q: What are the main benefits of using these plugs in Indian industries?

A: Main benefits include regulatory compliance, improved safety, early warning against dangerous boiler conditions, and suitability for various low-pressure industrial boilers used in Indian manufacturing sectors.

Q: How is the bronze fusible plug maintained for optimal performance?

A: Regular visual inspections, cleaning of surrounding areas to prevent buildup, and timely replacement after activation or damage are key maintenance practices to ensure the plug's reliable operation.
